SD10-L-28W
Ceiling Surface
Product number | ALST70 - 24 |
Input Voltage (v): | 220-240V AC |
Dimming | On/Off,Triac,1-10V,DALI |
Light source | COB LED |
luminaire Lifetime | 50.000h(L80-B10, Ta25°C) |
Rotation Angle (degree) | 350 |
Tilting Angle (degree) | 90 |
IP Rating | 20 |
Working Temperature (°C) | -5 ~ +30 |
Storage Temperature (°C) | -20 ~+50 |
Material | Aluminium |
Fitting Colors | 9016 Sandy White / 9017 Sandy Black |
N.W. lamp (Kg) | 0.76 |
G.W. Carton (Kg) | 12 |
Master carton dimensions(mm) | 720x295x220 |
Quantity per carton(PCS) | 10 |
Beam | Watt | CRI | Luminous | CCT | Code |
16 |
24W | 90 | 2012.1 lm | 4000K | ALST70S-NC24G40-S |
1898.2 lm | 3000K | ALST70S-NC24G30-S | |||
1765.3 lm | 2700K | ALST70S-NC24G27-S | |||
21 |
24W | 90 | 2028.8 lm | 4000K | ALST70S-NC24G40-M |
1914.0 lm | 3000K | ALST70S-NC24G30-M | |||
1780.0 lm | 2700K | ALST70S-NC24G27-M | |||
34 |
24W | 90 | 1911.4 lm | 4000K | ALST70S-NC24G40-F |
1803.2 lm | 3000K | ALST70S-NC24G30-F | |||
1676.9 lm | 2700K | ALST70S-NC24G27-F | |||
45 |
24W | 90 | 1926.9 lm | 4000K | ALST70S-NC24G40-WF |
1817.8 lm | 3000K | ALST70S-NC24G30-WF | |||
1690.6 lm | 2700K | ALST70S-NC24G27-WF |
